10L Ultrasonic Parts Cleaner | Cylinder Head & Transmission Valve Cleaner

The 10-liter ultrasonic parts cleaner can speed up your cleaning job for the general automotive repair shop while you are taking 5-15 vehicles per day, and if you were taking more time to clean the carbon-covered cylinder heads, varnish-filled intake manifolds, and the brake dust-packed caliper housing that slow down your cleaning job.

240W Ultrasonic Output-Optimized for Mid-Size Automotive Components

There are four 40 kHz ultrasonic transducers bonded to the bottom of the cleaning tank delivering 240 W ultrasonic cleaning power. It is an optimized design for cleaning automotive components, such as inline 4-cylinder heads, transmission valve bodies, and brake caliper housing. Compared to the 6L cleaner, the 240W ultrasonic cleaning power density is ideal for parts in the 2-6 kg range, such as the typical workload of a general automotive repair shop, which can save cleaning time by 25%.

380 x 250 mm Tank-Fits Inline-4 and V6 Cylinder Heads

10L cleaning has a relatively large cleaning tank compared with 6L, so it accommodates inline-4 and most V6 cylinder heads in a single layer, or two inline-4 cylinder heads can be placed side by side instead of overlapping, which will not affect the ultrasonic cleaning penetration. So that it can double throughout for cylinder head reconditioning shops.

400W Heating System - Fast Warm-Up for 10L Solution Volume

The machine has a high-power heating element due to the larger cleaning tank, which ensures the heating speed will be kept short. For example, it brings the 10 L solution from room temperature 20 C to 80 C in approximately 25 minutes.

Variable Power Control-20-100% for Aluminum to Cast Iron

There is a wide material range in mid-size automotive components, such as aluminum cylinder heads, cast iron engine blocks, steel crankshafts, and plastic intake manifolds. The 0-100% digital power output control lets you set 25%-35% for aluminum heads, 50%-60% for steel components, and 80%-90% for cast iron blocks with baked-on carbon. This function eliminates the component damage risk across diverse ultrasonic cleaner power.

Digital Timer 0-24H - Overnight Cycle for Batch Processing

It has a long life span; you can load the cylinder head and intake manifolds at the end of the day, set an 8-12 hour cycle, and return to clean components the next morning. The digital LCD display elapsed time on the LCD panel, allowing workers to track cycle progress at a glance. Auto-shutoff engages when the timer expires-no supervision is required during operation.

SUS304 2.5mm Chamber-Proven Durability in Daily Shop Use

The 380 x 250 x 200 mm inner tank is formed from 2.5 mm SUS304 stainless steel with TIG-welded corners. It tolerates continuous exposure to pH 10-12 alkaline degreasers, citric acid descalers (up to 10% concentration), and isopropanol-based solvent flushes. A 2-degree floor slope toward the 3/8-inch drain valve ensures complete solution evacuation. The tank is rated for 10+ years of daily shop use.

General Automotive Repair

The 10L cleaner has 380 X 250 X 200mm tank fits most inline-4 cylinder heads and many V6 head. So that it is specially good for cleaning inline-4 and V6 cylinder heads, intake manifolds, and the brake caliper housings from passenger cars and light commercial vehicles. It helps to remove combustion carbon from valve seats, oil varnish from intake ports, and brake dust from caliper bores. Simply, 10-12 minutes at 70% power, 65 C a cycle.

Transmission Valve Body Reconditioning

The cleaning process is essential before valve body pressure testings and reassembly, it make the parts in perfect status. Using 25%-35% ultrasonic power for aluminum valve bodies to avoid surface pitting, meanwhile, The 200mm depth accommodates valve bodies in the vertical orientation which make the solution circulation through all spool bores and orifice passages.

Brake Caliper and Hub Assembly Service

Removing brake dust, rust inhibitor residues, and corrosion from machined surface that must be measured for wear limits, while cleaning brake caliper housings, wheel hub assemblies, and steering knuckles. The 10L tank size allow cleaning of 4-6 brake calipers per cycle, keeping brake service downtime to a minimum, which make the 25% save time, and cleaning effect more effective than traditional cleaning way.

Intake Manifold and Throttle Body Cleaning

There are so many deposits from passage that can not be reached by hand-cleaning tools, such as intake manifolds, throttle bodies, and EGR( exhaust gas re-circulation) valves, Carbon deposits from PCV( positive crankcase ventilation) and EGR flow accumulate on intake tract surface reducing engine efficiency.

Fuel System Component Overhaul

This machine can clean the fuel injector bodies, fuel rail assemblies, and the throttle posistion sensor housings more effectively. The cavitation phenomenon can remove the stain or dust on the surface or the inner inner structure, such as tunnel, hole, and gap. which can't be thoroughly by traditional cleaning methods.

Motorcycle and Powersports Engine Service

The 10L capacity cleaning tank is the ideal size for cleaning motorcycle engine components, such as inline-4 motorcycle cylinder heads, which is the size fits within 380 X 250mm tank floor. The strong ultrasonic cleaning power can remove carbon from combustioin chambers, varish from the intake sports, and gear oil residues. Normally, 8-10mins at 60-70% power at 60 C is enough.

We are the professional ultrasonic product supplier who have our own vertical production line on site. That supports us to provide you with the following OEM/ODM service.

Specification modification: We produce piezo ceramic ultrasonic cleaning transducers so that not only do we adjust the tank dimension, but also we can match the proper ultrasonic cleaning transducer according to the adjustment to ensure the cleaning effect. Such as power output, heating capacity, or the control panel, etc.

• Certification Support: We have a certification engineer who can assist with CE, FCC, RoHS, and regional certification requirements for target markets including North America, Europe, and Australia/New Zealand.

• MOQ Flexibility:

Competitive minimum order quantities (50 pcs) for equipment distributors and shop chains.

Sample policy

Free sample, but freight should be collected, and the sample ready period is 3-7 days.
